Service Sink – Parametric Revit Family

This Service Sink Revit Family can create all the different versions you will need for your next project. From Curved, Square to Rectangular shape based. Consistent graphics all across the views!

See additional information section for more details.

• Show/Hide – Rear/Left/Right Splashguard, Faucet, Front Curb Drop
• Adjust Sink Overall Width and Length, Curb Height and Thickness
• Revit Pipe Drain Connection Included in the family. Adjust pipe diameter
• Sink, Faucet, Splash guard Materials

Files included with Purchase:

• Service Sink-Corner Curved- Plumbing Fixture Revit Family
• Service Sink-Corner Square- Plumbing Fixture Revit Family
• Service Sink-Corner Rectangle- Plumbing Fixture Revit Family

Family Features:

• 100% Parametric: Ready-to-use fully parametric smart line-based family built inside the Revit family environment.
• Full Customization: Single Family creates all different listed types & more.
• Ease of Use: Easily create your own version in a flash with logically created Instance/Type parameters within the family.
• Managed BIM: Swap 2D Annotations, 3D fixture models, or materials anytime to add your own version with the in-built Nested Families.
• Consistent around Views: Consistent graphics across the plan, elevation, sections, and 3D
• Consistent around Phases: Use the same family from preliminary through the construction documentation
• Integrate Everywhere: Easily integrates into office-wide Revit Standards, templates, custom-built families, and applications.

Version Log:

Version 1 –

• Service Sink Family Creation
