Roof Jack Vent Round – Revit Family

This single Roof Jack Vent Revit Family can create all the different versions you will need for your next project. Consistent graphics all across the views! Roof Slope parameter for perpendicular vent to the roof and Roof Thickness parameter to make sure vent penetration void cut the roof all the way for proper graphic in 3d view.

Family Parameters:

• Roof slope and Roof thickness
• Vent Diameter and Height
• Visiblity – Vent Cap and Boot
• Vent & Boot Material

Files included with Purchase:

• Roof Jack Vent Round – Generic Model Face Based Revit Family

Family Features:

• 100% Parametric: Ready-to-use fully parametric smart line-based family built inside the Revit family environment.
• Full Customization: Single Family creates all different listed types & more.
• Ease of Use: Easily create your own version in a flash with logically created Instance/Type parameters within the family.
• Managed BIM: Swap 2D Annotations, 3D fixture models, or materials anytime to add your own version with the in-built Nested Families.
• Consistent around Views: Consistent graphics across the plan, elevation, sections, and 3D
• Consistent around Phases: Use the same family from preliminary through the construction documentation
• Integrate Everywhere: Easily integrates into office-wide Revit Standards, templates, custom-built families, and applications.

Version Log:

Version 1 –

• Roof Jack Vent Round Family Creation
