Jersey Barrier with Fence – Revit Family

This single Jersey Barrier Railing Revit Family can create all the different versions you will need for your next project. Create your own versions of Jersey barrier types with predefined parameters. Consistent graphics all across the views!

Family Baluster Profile Parameters:

• Adjust Barrier overall depth, height, length and base height
• Show/Hide – Fence, Intermidiate Fence Post

Railing types included with Purchase:

• EXT – 4′ Jersey Barrier-Concrete
• EXT – 4′ Jersey Barrier-Concrete & Fence w/ 2′ Gap
• EXT – 4′ Jersey Barrier-Concrete & Gap
• EXT – 4′ Jersey Barrier-Concrete w/ 2′ Gap
• EXT – 4′ Jersey Barrier-Plastic
• EXT – 4′ Jersey Barrier-Plastic & Fence
• EXT – 4′ Jersey Barrier-Plastic & Fence w/ 2′ Gap
• EXT – 4′ Jersey Barrier-Plastic w/ 2′ Gap
• EXT – 8′ Jersey Barrier-Concrete
• EXT – 8′ Jersey Barrier-Concrete & Fence
• EXT – 8′ Jersey Barrier-Concrete & Fence w/ 2′ Gap
• EXT – 8′ Jersey Barrier-Concrete w/ 2′ Gap
• EXT – 8′ Jersey Barrier-Plastic
• EXT – 8′ Jersey Barrier-Plastic & Fence
• EXT – 8′ Jersey Barrier-Plastic & Fence w/ 2′ Gap
• EXT – 8′ Jersey Barrier-Plastic w/ 2′ Gap
• EXT – 10′ Jersey Barrier-Concrete
• EXT – 10′ Jersey Barrier-Concrete & Fence
• EXT – 10′ Jersey Barrier-Concrete & Fence w/ 2′ Gap
• EXT – 10′ Jersey Barrier-Concrete w/ 2′ Gap
• EXT – 10′ Jersey Barrier-Plastic
• EXT – 10′ Jersey Barrier-Plastic & Fence
• EXT – 10′ Jersey Barrier-Plastic & Fence w/ 2′ Gap
• EXT – 10′ Jersey Barrier-Plastic w/ 2′ Gap
• EXT – 12′ Jersey Barrier-Concrete
• EXT – 12′ Jersey Barrier-Concrete & Fence
• EXT – 12′ Jersey Barrier-Concrete & Fence w/ 2′ Gap
• EXT – 12′ Jersey Barrier-Concrete w/ 2′ Gap
• EXT – 12′ Jersey Barrier-Plastic
• EXT – 12′ Jersey Barrier-Plastic & Fence
• EXT – 12′ Jersey Barrier-Plastic & Fence w/ 2′ Gap
• EXT – 12′ Jersey Barrier-Plastic w/ 2′ Gap
• Sample Revit Project File

Family Features:

• 100% Parametric: Ready-to-use fully parametric smart line-based family built inside the Revit family environment.
• Full Customization: Single Family creates all different listed types & more.
• Ease of Use: Easily create your own version in a flash with logically created Instance/Type parameters within the family.
• Managed BIM: Swap 2D Annotations, 3D fixture models, or materials anytime to add your own version with the in-built Nested Families.
• Consistent around Views: Consistent graphics across the plan, elevation, sections, and 3D
• Consistent around Phases: Use the same family from preliminary through the construction documentation
• Integrate Everywhere: Easily integrates into office-wide Revit Standards, templates, custom-built families, and applications.

Version Log:

Version 1 –

• Jersey Barrier Railing Family Creation
