Door & Window Tag – Parametric Revit Family

The Door/Window Tag Revit Family can create all the listed different iterations you will need for your next project. Create consistent & headache free Door/Window tags across your project. This family is based off the system parameters and uses default Door width and height family parameter to display door information, so no need to add any extra shared parameters! There is also Description & Comment family parameter included for extra information. The only time you will have to add shared parameter is when you want to use the Door tag with hardware group type, otherwise these tags will work just fine.

See Family in action:
Video coming soon:

Family Parameters:

• Switch between listed tag types
• Door Hardware Type Shared Parameter if it requires
• Imperial and Metric Tag Types

Files included with Purchase:

• Door Tag – Revit Door Tag Family – Imperial and Metric Types
• Window Tag – Revit Window Tag Family – Imperial and Metric Types
• Sample Project for Imperial and Metric Type

Family Features:

• 100% Parametric: Ready-to-use fully parametric family built inside the Revit family environment.
• Full Customization: Single Family creates all different listed types & more.
• Ease of Use: Easily create your own version in a flash with logically created Instance/Type parameters within the family.
• Managed BIM: Swap between different tag types anytime to add your own version.
• Consistent around Views: Consistent graphics across the plan, elevation, and sections.
• Consistent around Phases: Use the same family from preliminary through the construction documentation
• Integrate Everywhere: Easily integrates into office-wide Revit Standards, templates, custom-built families, and applications.

Version Log:

Version 3 –

• Imperial Tags – Fixed tag display when fractions of inches is used on door/window sizes. Now, it round down tags to display in inches instead of fractions.

Version 2 –

• Opaque background for tag labels
• Window Imperial tag w/ head height missing numbers dash added back to the family
